Product advantages
UVC disinfection is a physical process that destroys bacteria as soon as they pass through the UV lamp in the chamber.
Through the studies, UV ray mainly kills the microbes (pathogene such as germs, virus etc) by radiation damage and function destruction of nucleic acid for the purpose of sterilization.
UV rays can cause the breakage of nucleic acid's strand, inter-strand cross-linking and formation of photochemical products, etc. thus to change the biological activity of DNA and inhibit the reproduction of microbes.
Therefore, this UV damage is also fatal.UV radiation (UVC) can destructthe DNA of microbes irreversibly so that they can not reproduce until death finally.
Product Application
 Swimming Pool Water |
| Campus Water Seilization |
| Non-Soil Cltvation |
Product Video
Parameter
| Model | Flow Rate @ 30mj/cm⊃2; | Lamp Watts | Inlet/outlet Port | Reactor Size(mm) |
| GPM | TPH | L | W | H |
| AMD-RUV-4 | 0.3 | 0.07 | 4 | 1/4" F Thread | 200 | 51 | 70 |
| AMD-RUV-6 | 0.5 | 0.12 | 6 | 1/4" F Thread | 260 | 51 | 70 |
| AMD-RUV-11 | 1 | 0.23 | 11 | 1/4" F Thread | 260 | 51 | 70 |
| AMD-RUV-16 | 2 | 0.45 | 16 | 1/2" F Thread | 375 | 63 | 80 |
| AMD-RUV-25 | 6 | 1.4 | 25 | 1/2" F Thread | 518 | 63 | 90 |
| AMD-RUV-30 | 8 | 1.8 | 30 | 3/4" F Thread | 975 | 63 | 90 |
| AMD-RUV-40 | 10 | 2.3 | 40 | 3/4" F Thread | 890 | 63 | 90 |
| AMD-RUV-40 | 12 | 2.7 | 40 | 1" F Thread | 920 | 63 | 90 |
| AMD-RUV-55 | 12 | 2.7 | 55 | 3/4" F Thread | 975 | 63 | 90 |
| AMD-RUV-80 | 24 | 5.5 | 80 | 1" F Thread | 950 | 63 | 90
|
UV Light Purification Advantage Than Others Way
Methods | UV | Chlorination | Ozone |
| Destruction | Physical | Chemical | Chemical |
| Capital Cost | Low | Medium | High |
| Operating Cost | Low | Medium | High |
| Maintenance Cost | Low | Medium | High |
| Maintenance Frequency | Low | Medium | High |
| Disinfection Performance | Excellent | Very good | Unpredictable |
Contact time | 1-5 Seconds | 25-24 minutes | 5-10 Minutes |
| Persanal Hazards | Low | Medium | High |
| Toxic Chemicals | No | Yes | Yes |
| Water Chemistry Change | No | Yes | Yes |
| Residual Effect | No | Yes | Yes |
