Purified Water Systems for Pharmaceuticals
Equipment Features
Simple & Reliable Structure: Designed for easy disassembly and maintenance.
Standardized Components: Actuators use modular, universal parts for quick replacement and cleaning.
Smooth & Sterilizable Surfaces: Internal/external walls are smooth, non-porous, and free of dead corners. Surfaces are chrome-plated or corrosion-treated; paint-free to avoid flaking.
Purified Water Equipment: Made of low-carbon stainless steel or validated non-contaminating materials. Regular cleaning and validation are required.
Water for Injection (WFI) Equipment: Constructed with high-grade stainless steel (e.g., 316L) or validated materials. Periodic cleaning and validation mandatory.
Purified Water Storage
Storage time ≤24 hours; tanks use stainless steel or validated non-toxic materials.
Venting ports fitted with hydrophobic sterilizing filters (non-shedding).
Smooth inner walls, no dead legs or pores in welds/joints.
Sensors for level/temperature/pressure must prevent stagnant water contamination.
Regular cleaning, sterilization, and validation required.
Application
Source water for Water for Injection (WFI) preparation
Water for non-sterile pharmaceutical ingredient mixing and non-sterile API purification processes
Solvent or testing water for conventional pharmaceutical preparations
Extraction solvent for herbal injections, eye drops, and other sterile preparations
Solvent or diluent for oral and topical dosage forms
Extraction solvent for non-sterile herbal preparations
Final rinse water for equipment, utensils, and packaging materials in direct contact with drugs
Pre-wash water for packaging materials in direct contact with non-sterile textiles
Precision rinse water for non-sterile pharmaceutical utensils
Product Model
| Model | Capability(T/H) | Operation(MPa) | Membrane(Inch) | Membrane(Qty) | Power(KW) |
| AMDRO-125L | 0.125 | 1.0-1.4 | 4021 | 1 | 1.1 |
| AMDRO-250L | 0.25 | 1.0-1.4 | 4040 | 1 | 1.1 |
| AMDRO-500L | 0.5 | 1.0-1.4 | 4040 | 2 | 1.5 |
| AMDRO-750L | 0.75 | 1.0-1.4 | 4040 | 3 | 2.2 |
| AMDRO-1000L | 1 | 1.0-1.4 | 4040 | 4 | 2.2 |
| AMDRO-1500L | 1.5 | 1.0-1.4 | 4040 | 6 | 3 |
AMDRO-2000L | 2 | 1.0-1.4 | 4040 | 8 | 3 |
AMDRO-3000L | 3 | 1.0-1.4 | 4040 | 12 | 4 |
AMDRO-5000L | 5 | 1.0-1.4 | 8040 | 5 | 5.5 |
AMDRO-10000L | 10 | 1.0-1.4 | 8040 | 10 | 11 |
AMDRO-15000L | 15 | 1.0-1.4 | 8040 | 15 | 15 |
AMDRO-20000L
| 20 | 1.0-1.4 | 8040 | 20 | 18.5 |
