Fiberglass Reinforced Plastic Tanks

Working Pressure:150psi (10.5bar)
Working Temperature:1-49*C (34-121*F)
Max.Vacuum:127mm Hg
Lowest Environment Temperature: -27*C (-17*F)


Availability:



Inquire

Model:
AMD-FRP
Brand:
Amanda

Product Description

Backwash Tank for Water Treatment

Fiberglass reinforced plastic tanks

MAIN TECHNICAL FEATURE

Fiberglass reinforced plastic tanks

AMANDA-S TANK SPECIFICATION

Model	Vessel Size		Vol	Opening		Dimension/mm				Base
Model	Inch	mm	L	Top	Bot.	LA	LB	LC	D	Base
0713/2.5T	7x13	181x335	6.3	2.5"NPSM	/	335	330	/	181	PP
0717/2.5T	7x17	181x440	8.5	2.5"NPSM	/	440	435	/	181	PP
0735/2.5T	7x35	181x895	19.1	2.5"NPSM	/	895	890	/	181	PP
0744-2.5T	7x44	181x1125	24.3	2.5"NPSM	/	1125	1120	/	181	PP
0813/5T	8x13	205x335	7.4	2.5"NPSM	/	335	330	/	205	PP
0817/2.5T	8x17	205x440	10.5	2.5"NPSM	/	440	433	/	205	PP
0835/2.5T	8x35	205x 895	23.6	2.5"NPSM	/	895	888	/	205	PP
0844/2.5T	8x44	205x1125	31.3	2.5"NPSM	/	1125	1118	/	205	PP
0917/2.5T	9x17	232x440	13.2	2.5"NPSM	/	440	890	/	232	PP
0935/2.5	9x35	232x898	31.6	2.5"NPSM	/	898	1067	/	232	PP
0942/2.5T	9x42	232x1074	38.5	2.5"NPSM	/	1074	1221	/	232	PP
0948/2.5	9x48	232x1228	44.6	2.5"NPSM	/	1228	430	/	232	PP
1017/2.5T	10x17	257x450	16.5	2.5"NPSM	/	450	890	/	257	PP
1035/2.5T	10x35	257x910	38.3	2.5"NPSM	/	910	1114	/	257	PP
1044/2.5T	10x44	257x1130	49.5	2.5"NPSM	/	1130	1370	/	257	PP
1054/2.5T	10x54	257x1388	61.9	2.5"NPSM	/	1388	1214	/	257	PP
1248/2.5T	12x48	307x1220	77.3	2.5"NPSM	/	1220	1328	/	307	PP
1252/2.5T	12x52	307x1335	84.8	2.5"NPSM	/	1335	1640	/	307	PP
1265/2.5T	12x65	307x1650	106.3	2.5"NPSM	/	1650	1127	/	307	PP
1344/2.5T	13x44	334x1135	82.9	2.5"NPSM	/	1135	1392	/	334	PP
1354/2.5T	13x54	334x1400	103.6	2.5"NPSM	/	1400	1780	/	334	PP
1465/2.5T	14x65	360x1662	145.6	2.5"NPSM	/	1662	1654	/	360	PP
1465/4T	14x65	360x1662	145.6	4"-8UN	/	1662	1654	/	360	PP
1665/2.5T	16x65	410x1670	187.7	2.5"NPSM	/	1670	1662	/	410	PP
1665/4T	16x65	410x 1670	187.7	4"-8UN	/	1670	1662	/	410	PP
1665/4T4B	16x65	410x 1830	187.7	4"-8UN	4"-8UN	1830	1650	180	410	FRP Tripod
1865/4T	18x65	465x 1675	249	4"-8UN	/	1670	1660	/	465	FRP Round
1865/4T4B	18x65	465x 1825	249	4"-8UN	4"-8UN	1830	1650	180	465	FRP Tripod

AMANDA-H TANK SPECIFICATION

Model	Vessel Size		Vol	Opening		Dimension/mm				Base
Model	Inch	mm	L	Top	Bot.	LA	LB	LC	D	Base
H2162/4T-R	21x62	550x 1650	326	4"-8UN	/	1650	1600	/	550	FRP Round
H2162/4T	21x62	550x1910	326	4"-8UN	/	1910	1600	/	550	FRP Tripod
H2162/4T4B	21x62	550x1910	326	4"-8UN	4"-8UN	1910	1590	320	550	FRP Tripod
H2472/4T-R	24x72	615x1890	471	4"-8UN	/	1890	1839	/	615	FRP Round
H2472/4T	24x72	615x2150	471	4"-8UN	/	2150	1839	/	615	FRP Tripod
H2472/4T4B	24x72	615x2150	471	4"-8UN	4"-8UN	2150	1830	320	615	FRP Tripod
H3072/4T-R	30x72	780x 1860	758	4"-8UN	/	1860	1839	/	780	FRP Round
H3072/4T	30x72	780x2150	758	4"-8UN	/	2150	1830	/	780	FRP Tripod
H3072/4T4B	30x72	780x2150	758	4"-8UN	4"-8UN	2150	1830	320	780	FRP Tripod
H3672/4T4B	36x72	918x2150	1023	4"-8UN	4"-8UN	2150	1830	320	918	FRP Tripod
H3672/6T6B	36x72	918x2260	1023	6"-flane	6"-flange	2260	1940	320	918	FRP Tripod
H4272/6T6B	42x72	1088x2270	1389	6"-flane	6"-flange	2270	1950	320	1088	FRP Tripod
H4872/6T6B	48x72	1218x2270	1743	6"-flane	6"-flange	2270	1950	320	1218	FRP Tripod
H6370/6T6B	63x70	1620x1780	2580	6"-flane	6"-flange	2100	1780	320	1620	FRP Tripod
H6383/6T6B	63x83	1620x 2080	3150	6"-flane	6"-flange	2400	2080	320	1620	FRP Tripod

AMANDA-D TANK SPECIFICATION

Model	Vessel Size		Vol	Opening			Dimension/mm				Base
Model	Inch	mm	L	Top	Bot.	Dis.	LA	LB	LC	D	Base
4272/6T6B4D	42x72	1088x1850	1100	6"-flange	6"-flange	4"-flange	1850	1615	235	1088	FRP Tripod
4289/6T6B4D	42x89	1088x2270	1389	6"-flange	6"-flange	4"-flange	2270	1950	320	1088	FRP Tripod
4872/6T6B4D	48x72	1218x1850	1308	6"-flange	6"-flange	4"-flange	1850	1565	285	1218	FRP Tripod
4889/6T6B4D	48x89	1218x2270	1743	6"-flange	6"-flange	4"-flange	2270	1950	320	1218	FRP Tripod
4894/6T6B4D	48x94	1218x2400	1909	6"-flange	6"-flange	4"-flange	2400	2110	290	1218	FRP Tripod
48110/6T6B4D	48x110	1218x 2800	2360	6"-flange	6"-flange	4"-flange	2800	2510	290	1218	FRP Tripod
6094/6T6B4D	60x94	1530x2400	2688	6"-flange	6"-flange	4"-flange	2400	2110	290	1530	FRP Tripod
60110/6T6B4D	60x110	1530x2800	3392	6"-flange	6"-flange	4"-flange	2800	2510	290	1530	FRP Tripod
6383/6T6B4D	63x83	1620x2100	2580	6"-flange	6"-flange	4"-flange	2100	1780	320	1620	FRP Tripod
6394/6T6B4D	63x94	1620x2400	3150	6"-flange	6"-flange	4"-flange	2400	2080	320	1620	FRP Tripod
★7294/6T6B4D	★72x94	1836x2400	3561	6"-flange	6"-flange	6"-flange	2400	2045	355	1836	FRP Tripod
H4272/6T6B4D	42x72	1088x2270	1389	6"-flange	6"-flange	4"-flange	2270	1950	320	1088	FRP Tripod
H4872/6T6B4D	48x72	1218x2270	1743	6"-flange	6"-flange	4"-flange	2270	1950	320	1218	FRP Tripod
H6370/6T6B4D	63x70	1620x1780	2580	6"-flange	6"-flange	4"-flange	2100	1780	320	1620	FRP Tripod
H6382/6T6B4D	63x82	1620x2080	3150	6"-flange	6"-flange	4"-flange	2400	2080	320	1620	FRP Tripod

*The actual dimmension may have ±1.2% error due to PE materlats contraction coefficient

PRODUCT DISPLAY

Product advantage:

FRP tank is made up of resin and glass fiber by microcomputer control winding machine and become a kind of non-metallic

comoosite tanks. it has corrosion resistance. hiah strenath. lona service life. can be flexible desian. workmanshiD, etc

PRODUCING PROCESS

Our FRP tanks are manufactured by modern automated filament winding process in conformity with export standard.

The FRP tank has a high performance epoxy resin coated fiberglass strands outer shell with polyethylene (PE) or ABS seamless one-piece liner.

The tank with two layers of protection is superior corrosion resistant and rustproof.

FRP Water Pressure Tank (7)

PRODUCTION PROCESS

AMD PRODUCTION PROCESS

PACKAGE AND SHIPPING

We have our own freight forwarding with a fleet of both trucks and trailers to accommodate our tank, thus we can ship your bulk orders in one load, saving you time and money!
